Bus Shelter Station-HCT-0134

Product Overview

The Bus Shelter Station HCT-0134 reimagines transit infrastructure as a multi-functional mobility hub, designed to accommodate high passenger volumes while integrating essential amenities for modern commuters. This large-capacity shelter serves as a central transfer point for multiple routes, combining weather protection with smart technologies that enhance the passenger experience. Its modular design allows customization to specific location needs, from basic transit stops to fully equipped mobility centers, making it ideal for busy urban intersections and suburban transit hubs.

Product Features

High-Capacity Structure

Built with 3mm galvanized steel frame and 2mm aluminum roof panels, the shelter accommodates up to 20 standing passengers or 12 seated passengers across its 9000mm length. The frame undergoes hot-dip galvanization (80μm zinc coating) followed by electrostatic powder coating for superior corrosion resistance, ensuring 15+ year lifespan in various climates. Reinforced roof structure supports 1.0kN/m² snow load (100kg/m²), making it suitable for regions with heavy winter precipitation.

Integrated Smart Technologies

Features dual 55″ 4K digital displays (one for route information, one for advertising) with 2500 nits brightness for readability in direct sunlight. The displays connect via Wi-Fi 6 or 4G to transit management systems, showing real-time arrival information, service disruptions, and alternative routes. Optional passenger counting sensors gather ridership data to optimize service frequency, while LED lighting with daylight harvesting adjusts brightness automatically to save energy.

Enhanced Passenger Amenities

Includes ergonomic stainless steel seating (4 individual benches with backrests), USB charging ports (8×5V/2.1A) integrated into seating arms, and real-time passenger information system with audio announcements. The shelter features tinted polycarbonate side panels (6mm thick) that reduce solar gain by 40% while protecting against wind and rain. A recycling station (2-compartment, 30L each) promotes sustainable urban practices, while clear signage ensures intuitive wayfinding.

Application

Perfect for major transit intersections, downtown transfer points, suburban activity centers, and transportation terminals where multiple bus routes converge. Ideal for university campuses with high student ridership, medical districts serving patients and staff, and commercial centers with peak-hour commuter traffic. The shelter’s smart technology integration makes it a cornerstone of bus rapid transit (BRT) systems, providing passengers with the information needed to make seamless transfers.

FAQ

Q: How is the shelter customized for different transit needs?

A: The modular design allows tailoring length (6000mm–12000mm), adding or removing display screens, incorporating bike storage (accommodating 4–6 bikes), or integrating a small ticket vending machine for transit passes. For high-security areas, we can add CCTV integration and emergency call buttons connected to transit authorities.

Q: How does the real-time information system stay updated?

A: The displays connect to municipal transit management systems via secure API integration, updating arrival times every 30 seconds. In areas with poor connectivity, the system caches data and continues operating with scheduled information, automatically syncing when connection is restored. Manual override capability allows transit staff to post emergency announcements instantly.

Q: What maintenance is required for the digital components?

A: The displays feature front-access maintenance design allowing technicians to service components without disassembling the shelter. Scheduled maintenance is recommended every 6 months, including screen cleaning, software updates, and cooling system inspection. The displays are rated for 50,000 hours of operation (over 5 years of continuous use) before any brightness degradation occurs.
